- eOpic
- 5
5-inch EO/IR payload
The eOpic-5 is a light-weight dual-axis gyro-stabilized electro-optical system designed for advanced ISR missions.
EOPIC-5 KEY FEATURES
- EO/IR payload
- Integrated INS
- Fully featured mission software
- STANAG 4609
- Georeferenced imagery
- Automatic target tracking
SYSTEM FEATURES BREAKDOWN
eOpic-5 technical specifications
Download onepager (opens in a new tab)Imaging payload
-
Type: 2-axis gyro-stabilized
GPS: GPS L1, Galileo, SBAS -
Features on-board
Automatic target tracking
Scene tracking
Geo-pointing
Picture-in-picture
Visible camera
-
Type: FullHD
Resolution: 1920 x 1080 p
FOV: 63.7° – 2.3°
Zoom: 30x optical zoom, 3x digital zoom -
DRI human: 14 km / 6 km / 2.5 km
DRI vehicle: 22 km / 12 km/ 6 km
Thermal image
-
Type: LWIR
Resolution: 640 x 512 p
FOV: 18°
Zoom: 8x digital zoom -
DRI human: 1 280 m / 320 m / 160 m
DRI vehicle: 3 850 m / 950 m / 295 m
Video
-
Resolution: 1920 x 1080 p, 30 fps
Video encoding: MPEG4 AVC H.264
Metadata: STANAG 4609 (KLV)
Video stream: MPEG-TS
eOpic-5 HD Technical specifications
Download onepager (opens in a new tab)Imaging payload
-
Type: 2-axis gyro-stabilized
GPS: GPS L1, Galileo, SBAS -
Features on-board
Automatic target tracking
Scene tracking
Geo-pointing
Picture-in-picture
Visible camera
-
Type: FullHD
Resolution: 1920 x 1080 p
FOV: 65.4° – 3.0°
Zoom: 30x optical zoom, 3x digital zoom -
DRI human: 14 km / 6 km / 2.5 km
DRI vehicle: 22 km / 12 km/ 6 km
Thermal image
-
Type: HD LWIR
Resolution: 1280 x 1024 p
FOV: 20°
Zoom: 8x digital zoom -
DRI human: 1 750 m / 600 m / 300 m
DRI vehicle: 3 850 m / 1 450 m / 740 m
Video
-
Resolution: 1920 x 1080 p, 30 fps
Video encoding: MPEG4 AVC H.264
Metadata: STANAG 4609 (KLV)
Video stream: MPEG-TS
